How does a POE++ switch work?

How does a POE++ switch work?

February 25, 2022

How does a POE++ switch work?



A PoE++ switch works by delivering both power and data through Ethernet cables, specifically to devices that require higher wattage than standard PoE (Power over Ethernet) and PoE+ can provide. Unlike earlier versions of PoE, which supply 15.4W (PoE) or 30W (PoE+) per port, PoE++ can deliver up to 60W or 100W per port, enabling it to power a broader range of devices with higher power requirements.



Core Working Mechanism of PoE++ Switches

1. Power Delivery through Ethernet

PoE++ switches utilize Ethernet cables, typically Category 5e or Category 6 cables, to transmit both power and data to connected devices. This is achieved through the IEEE 802.3bt standard, which allows power to flow through two or all four pairs of twisted wires within the Ethernet cable, depending on the power requirement of the connected device.

--- Type 3 PoE++ (up to 60W): Uses four pairs of wires but allows for lower power devices by using only two pairs when needed.

--- Type 4 PoE++ (up to 100W): Uses all four pairs of wires to deliver maximum power for high-consumption devices.

2. Power Detection and Classification

PoE++ switches use sensing and negotiation mechanisms to identify whether a connected device (powered device, or PD) is PoE-compatible and determine its power requirements before delivering power.

--- Detection: When a device is connected, the PoE++ switch checks the line to detect if it is PoE-capable by applying a small test current and measuring the response. This ensures power isn’t sent to non-PoE devices, preventing possible damage.

--- Classification: After detection, the PoE++ switch classifies the device based on its power needs. The IEEE 802.3bt standard defines up to Class 8 (100W) for PoE++, allowing the switch to adjust the power output based on the specific class of each device. The classification also helps manage power distribution efficiently across multiple ports, ensuring each connected device receives the correct wattage.

3. Power Distribution and Load Balancing

--- The PoE++ switch distributes power across its ports according to each device’s power classification. In high-density setups, the switch’s power budget (the maximum total wattage it can supply) becomes a critical factor. Advanced PoE++ switches often feature intelligent power management that dynamically allocates power, reducing the risk of overloading. If a connected device demands more power than the switch’s remaining power budget, the switch may prioritize certain devices or delay powering the additional device.

4. Data and Power Isolation

--- Although power and data share the same Ethernet cable, the PoE++ switch ensures they operate on separate circuits within the device. This prevents data interference and enables simultaneous transmission of data and power. The isolation is achieved through specialized circuitry that splits the power and data signals, ensuring a stable connection without data degradation.

5. Heat and Voltage Regulation

--- As higher power levels generate more heat, PoE++ switches come with enhanced cooling solutions, such as built-in fans or heat sinks. Additionally, the switch regulates the voltage delivered to each device, maintaining it within a safe range to avoid overheating and potential damage to either the switch or the connected devices.





Practical Example: PoE++ in Operation

Consider a PoE++ switch deployed in a large office building for security and connectivity needs. This switch powers several high-powered IP cameras with pan-tilt-zoom capabilities and Wi-Fi 6 access points. When each device is connected, the switch:

--- Detects if each device is PoE++ compatible.

--- Classifies the power requirements of each camera and access point.

--- Delivers up to 60W for each camera (if it falls under Type 3) and up to 100W for certain access points (Type 4).

--- Continuously monitors the power usage to ensure efficient allocation and prevent overloading, which is essential as the switch approaches its maximum power budget.





Key Considerations and Safety Mechanisms

--- Fault Protection: PoE++ switches are designed with built-in safety features to prevent excess power from reaching non-PoE devices. This includes short-circuit protection and safeguards against incorrect polarity.

--- Dynamic Power Allocation: If devices are removed or added, the switch dynamically reallocates the available power to maintain balance across the ports.

--- Overload Prevention: The switch can shut off power to specific ports if a device exceeds the switch’s power capacity, ensuring that critical devices stay online.





In summary, PoE++ switches efficiently manage and deliver high levels of power over Ethernet cables by detecting device requirements, intelligently distributing power, and maintaining network stability. They’re ideal for powering power-intensive devices while simplifying cabling and reducing installation costs, making them highly valuable in high-demand environments.
