Overview
S7500-48GE4GF-L2M, 48 Ports Managed Switch,with 4 Gigabit SFP Uplink,Support IPV4/IPV6
BENCHU GROUP's 48 port managed switch S7500-48GE4GF-L2M is a high-capacity networking solution designed to support the demands of growing businesses, data centers, and enterprise networks. With 48 fast Ethernet ports, it ensures seamless connectivity for a large number of devices, including PCs, IP cameras, VoIP phones, and access points. The 4 Gigabit SFP uplinks provide high-speed links to core switches, servers, or backbone networks, supporting both copper and fiber modules for flexibility.
This 48 port managed switch offers advanced management features like VLAN for network segmentation, QoS for traffic prioritization, and link aggregation to optimize bandwidth. Robust security options protect against unauthorized access and malicious traffic, ensuring reliable and secure network performance.
Ideal for large-scale office networks, campus environments, or surveillance systems, this 48 port managed switch brings significant value by enabling efficient traffic management, scalability, and stable high-speed connectivity. It simplifies complex network setups and supports smooth business operations.
-
Physical Port48-10/100/1000Mbps RJ45 Gigabit Ethernet ports4-1.25Gbps mini-GBIC SFP interface1-RJ45 console interface for switch management and setup1-Reset button for system factory default and rebootSwitchingSolid performance with non-blocking architecture ,64Gbps Backplane bandwidth47.62Mpps Switch Throughput9216 bytes Jumbo Framesupporting 16K MAC addressesAutomatic address learning and address agingHardware-based 10/100/1000Mbps auto-negotiation and auto MDI/MDI-XFlow control for full duplex operation and back pressure for half duplex operationSupports Energy-Efficient Ethernet (EEE) function (IEEE 802.3az)HardwareHigh- strength metal casing,19-inch Rack-Mount, 1U heightLED indicators for Power, LINK/ACTInternal AC power supply -
Layer 2 FeaturesSupport IEEE 802.1Q VLANSupport MAC VLANSupport Surveillance VLANSupport Voice VLANSupport QinQ VLANSupports Spanning Tree ProtocolSupports Link Aggregation (LACP)Supports port mirrorSupports Multicast Filtering (IGMP)Supports DHCPSupports ERPSSupports RMONSupports MLD snoopingSupports MVRSupports Quality of Service (Qos)Supports Static routingSupports Port Error DisableSupports Rate LimitSupports Storm Control -
SecuritySupport IEEE 802.1xSupport RADIUS accountingSupport Access Control Lists (ACLs)Support MAC SecuritySupport IP Source Guard prevents IP spoofing attacksSupport DoS Attack PreventionSupport aaa authenticationManagementIPv4 and IPv6 dual stack managementWeb switch managementConsole/Telnet Command Line InterfaceSNMP v1 and v2c switch managementSSHv2, TLSv1.2 and SNMP v3 secure accessFirmware upload/download via HTTP/TFTPConfiguration upload / download through Web interfaceHardware reset button for system reboot or reset to factory defaultSNTP Network Time ProtocolNetwork DiagnosticLink Layer Discovery Protocol (LLDP) Protocol and LLDP-MED
-
Features
High-Port Density for Extensive Connectivity
The S7500-48GE4GF features 48 Fast Ethernet ports, offering reliable connections for a wide range of devices such as workstations, IP cameras, VoIP phones, and wireless access points. Its high port density is designed for large-scale networks, making it ideal for enterprise offices, campuses, and data centers. With seamless communication across all ports and scalable options, this switch simplifies device integration while maintaining exceptional performance, ensuring your growing network operates smoothly and efficiently.
4 Gigabit SFP Uplink Ports for High-Speed Connections
Equipped with 4 Gigabit SFP uplink ports, this 48 port managed switch ensures high-speed and reliable connections to core switches, servers, or backbone networks. The SFP slots are compatible with both copper and fiber modules, providing flexibility for long-distance and high-bandwidth applications. These uplinks reduce network bottlenecks, enhance data transfer efficiency, and are critical for handling large volumes of traffic in demanding environments like enterprise networks or multi-floor buildings.
VLAN Support for Network Segmentation
VLAN functionality enables network segmentation to isolate traffic for improved security and efficiency. By creating separate zones for different departments or applications, VLAN reduces unnecessary broadcast traffic, enhances data protection, and ensures optimized performance. This feature is particularly useful in environments like corporate offices or campus networks, where secure and streamlined communication between distinct groups is essential.
Advanced QoS for Traffic Optimization
Quality of Service (QoS) allows the prioritization of critical data such as VoIP calls, video streaming, or high-volume file transfers. By ensuring bandwidth allocation based on priority, QoS minimizes delays and interruptions, guaranteeing a smooth experience for time-sensitive applications. This feature is vital in enterprise settings where uninterrupted service is required for productivity and collaboration.
Link Aggregation for Enhanced Bandwidth
This 48 port managed switch supports link aggregation, enabling multiple connections to be combined into a single high-speed link. This increases bandwidth, enhances redundancy, and ensures continuous network availability. Link aggregation is ideal for businesses requiring robust and fault-tolerant network setups, providing both scalability and reliability for high-demand applications like data storage and backup systems.
Robust Security Features
Comprehensive security tools, including Access Control Lists (ACLs), port security, and storm control, protect the network from unauthorized access and malicious traffic. ACLs enforce precise control over data flow, while storm control prevents bandwidth-consuming broadcast storms. These features ensure a safe and dependable environment for critical applications, making this 48 port managed switch suitable for organizations prioritizing data protection and compliance.
Easy Management and Monitoring
The S7500-48GE4GF features a user-friendly web-based interface and CLI for streamlined configuration and monitoring. Network administrators can easily manage settings like VLANs, QoS, and security policies while gaining real-time insights into performance. These intuitive management options simplify network deployment and troubleshooting, enabling businesses to maintain optimal network efficiency with minimal effort.
Connectivity Solutions
48 Port Managed Switch with 4 Gigabit SFP Uplink Connectivity Solutions
Specificatiions
Technical Specifications :
SP7500-48PGE4GF-L2M10M/100M/1G RJ45 copper ports :
481.25G SFP (fiber) ports :
4Console Port (For config ) :
Yes (For switch management and setup)Reset button :
Yes (For system factory default and reboot)Performance Specification :
*Packet buffer memory :
12MbForwarding modes :
Store-and-forwardBandwidth :
128 GbpsPacket forwarding rate :
78Mpps (64 byte packet size)MAC address database size :
16K (48-bit MAC ad-dresses)Jumbo frame support :
Up to 9K packet sizeL2 Services - VLANs :
*IEEE 802.1Q VLAN tagging :
YesQinQ VLAN tagging :
YesIP-based VLANs :
YesMAC-based VLANs :
YesProtocol-based VLAN :
YesVoice VLAN :
YesVLAN mapping :
YesL2 Services - Availability :
*Storm control :
Yes (Broadcast, multicast, unknown unicast)IEEE 802.3ad - LAGs (LACP) :
YesIEEE 802.3x :
YesRing (ERPS,complies with G.8032) :
Yes, Recovery time < 50msIEEE 802.1D Spanning Tree Protocol :
YesIEEE 802.1w Rapid Spanning Tree Protocol :
YesIEEE 802.1s Multiple Spanning Tree Protocol :
YesLayer 2 DHCP Relay :
YesL2 Services - Multicast Filtering :
*IGMP snooping (v1, v2 and v3) :
YesMLD snooping support (v1 and v2) :
YesIGMP snooping querier (v2) :
YesMLD snooping querier (v1) :
YesMulticast VLAN Registration (MVR) :
YesL3 Services - Routing :
*IPv4 static routing :
YesIPv6 static routing :
YesLink Aggregation :
*Manual LAG :
Yes# of LAGs / # of members in each LAG :
8 LAGs with max 8 members in each LAGNetwork Monitoring and Discovery Services :
*802.1ab LLDP :
YesSNMP :
v1, v2c, v3RMON group 1,2,3,9 :
YesNetwork Security :
*IEEE 802.1x :
YesRADIUS accounting :
YesAccess Control Lists (ACLs) :
YesIP-based ACLs (IPv4 and IPv6) :
L2 / L3 / L4MAC-based ACLs :
YesTCP/UDP-based ACLs :
YesControl MAC # static entries :
48Port-based security by locked MAC addresses :
YesDynamic ARP inspection :
YesDoS protection :
*DoS attacks prevention :
YesNetwork storm protection, DoS :
YesQuality of Service (QoS) :
*Port-based rate limiting :
Yes ingress and egressPort-based QoS :
YesSupport for IPv6 fields :
YesDiffServ QoS :
Yes ingressIEEE 802.1p COS :
YesDestination MAC and IP :
YesIPv4 and v6 DSCP :
YesTCP/UDP-based :
YesWeighted Round Robin (WRR) :
YesStrict priority queue technology :
YesIEEE Network Protocols :
*Protocols :
• IEEE 802.3 Ethernet • IEEE 802.3u 100BASE-T • IEEE 802.3ab 1000BASE-T • IEEE 802.3af PoE • IEEE 802.3at PoE+ • IEEE 802.3az Energy Efficient Ethernet (EEE) • IEEE 802.3ad Trunking (LACP) • IEEE 802.3z Gigabit Ethernet 1000BASE-SX/LXProtocols 2 :
• IEEE 802.3x Full-Duplex Flow Control • IEEE 802.1Q VLAN Tagging • IEEE 802.1AB LLDP with ANSI/TIA-1057 (LLDP-MED) • IEEE 802.1p Class of Service • IEEE 802.1D STP • IEEE 802.1s MSTP • IEEE 802.1w RSTP •Management, Monitoring & Troubleshooting :
*Password management :
YesAccess control via RADIUS and TACACS+ :
YesIPv6 management :
YesSNMP v1/v2c/v3 :
YesPort mirroring :
YesMany-to-one port mirroring :
24Cable test utility :
YesTLS/HTTPS Web-based access (version) :
Yes (v1.2)File transfers (uploads, downloads) :
TFTP / HTTPHTTP upload/download (firmware) :
YesSyslog (RFC 3164) :
YesLEDs :
YesPer port :
Speed, Link, Activity; or PoE in different modePer device :
Power, systemPhysical Specifications :
*Dimensions (Width * Depth * Height) :
440 x 290 x 44.5 mm (17.32 x 11.42 x 1.75 in)Weight :
4.35 kg (9.59 lb)Max power :
19W (worst case, all ports used, full PoE, line-rate traffic) (Watts)Iddle power consumption :
15W (all ports link-down standby) (Watts)Energy Efficient Ethernet (EEE) :
Yes (deactivated by default)Environmental Specifications :
*Operating Temperature :
-20° to 50°C (-4° to 122°F)Operating Humidity :
90% maximum relative humidity (RH), non-condensingOperating Altitude :
10,000 ft (3,000 m) maximumStorage Temperature :
–20° to 70°C (– 4° to 158°F)Storage Humidity (relative) :
95% maximum relative humidity, non-condensingStorage Altitude :
10,000 ft (3,000 m) maximumElectromagnetic Emissions and Immunity :
*Certifications :
CE mark, commercial; FCC Part 15 Class A, VCCI Class A; Class A EN 55022 (CISPR 22) Class A; Class A C-Tick; EN 55024; CCC; 47 CFR FCC Part 15, SubpartB, Class A ICES-003: 2016 Issue 6, Class A; ANSI C63.4:2014; IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013Safety :
*Safety Certifications :
CB mark, commercial; CSA certified (CSA 22.2 #950); EN 60950-1: 2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013 IEC 60950-1:2005; (ed.2)+A1:2009+A2:2013; AN/NZS 60950.1:2015; CCC (China Compulsory Certificate)Warranty and Support :
*Hardware Limited Warranty :
Limited Lifetime*Technical Support via Phone and Email* :
Limited Lifetime*24x7 Online Chat Technical Support :
Limited Lifetime*Package Contents :
*All models :
Smart Switch; AC Power cord with C13 connector (localized to region of sale) ; Brackets and screws for rack mounting; Rubber protection caps, which are already installed in the SFP sockets Installation guideBusiness Type :
CommercialBandridth :
1GMore Filters :
L2+ Managed
