IES7211-4PGE2GF-BOS, 4 Ports Booster PoE Switch,with 2 Gigabit SFP Uplink,DIN-Rail Mount, Redundant Power Input
Physical Port
Power over Ethernet
Switching
Hardware
Lightning Protection
Mechanical Properties
|
Layer 2 Features
Security
Management
|
Features
Advanced PoE Booster Technology
The IES7511-4PGE2GF-BOS is designed with 4 Gigabit Ethernet ports that support Power over Ethernet (PoE). What makes it unique is the built-in booster technology that converts 12V or 24V DC power to 48V POE power. This allows it to power standard PoE devices, such as IP cameras and wireless access points, in applications like buses, trains, or ships where only lower DC voltages are available. This feature is crucial for ensuring reliable operation in mobile or remote environments.
100W PoE Power Budget
This 4 Port PoE Booster switch supports IEEE 802.3af/at PoE, with up to 30W of power available on each PoE port, and max total power budget of 100W. This capability allows the switch to power multiple PoE-enabled devices simultaneously, such as cameras, access points, and IP phones, without the need for additional power infrastructure, thus simplifying installation and reducing costs.
Wide Operating Temperature Range
This PoE Booster switch is designed to operate reliably in harsh environments, with an operating temperature range from -40°C to 85°C. Its robust design ensures it can perform under extreme conditions, making it ideal for outdoor or industrial applications such as transportation, where temperature fluctuations are common.
IP40-rated Aluminum Housing for Durability
The IES7511-4PGE2GF-BOS is housed in an IP40-rated aluminum case that offers high durability and heat dissipation. This industrial-grade design protects the internal components from dust, dirt, and mechanical damage, ensuring longevity and stable performance even in challenging environments like factories or vehicles.
Dual Power Input for Reliability
This 4 Port PoE booster switch supports dual power inputs, providing redundancy to ensure stable operation. In cbse one power input fails, the switch can seamlessly switch to the backup power supply, minimizing downtime and ensuring continuous operation, which is particularly critical for mission-critical applications like transportation monitoring systems.
Advanced Traffic Management with QoS
For businesses or transportation applications requiring efficient traffic management, the switch features Quality of Service (QoS). This allows network administrators to prioritize critical data streams, such as real-time video or voice traffic, ensuring that essential services receive the necessary bandwidth for smooth operation.
Redundancy and Loop Prevention with ERPS
The IES7511-4PGE2GF-BOS supports advanced networking protocols such as ERPS (Ethernet Ring Protection Switching), STP/RSTP/MSTP to provide redundancy and prevent network loops. These features ensure that if one path fails, data can still be routed through alternative paths, maintaining network uptime and minimizing disruptions.
Connectivity Solutions
4 Port Booster PoE Switch for Rail Transit
4 Port Booster PoE Switch for Transit Transportation
Specification
Technical Specifications :
IE7511-4PGE2GF-BOS10M/100M/1G RJ45 copper ports :
41.25G SFP (fiber) ports :
2PoE / PoE+ ports :
4Power Supply Type :
DC 12V-24VConsole Port (For config ) :
YesReset button :
YesPower over Ethernet :
*PoE Standard :
IEEE 802.3at Power over Ethernet Plus/PSE; Backward compatible with IEEE 802.3af Power over EthernetPoE Power Supply Type :
End-span: 1/2 (+), 3/6 (-)PoE Power Output :
Per port 48V DC, 320mA. max. 15.4 watts (IEEE 802.3af); Per port 48V DC, 630mA. max. 30 watts (IEEE 802.3at)Performance Specification :
*Packet buffer memory :
1.6 MbForwarding modes :
Store-and-forwardBandwidth :
24 GbpsPacket forwarding rate :
8.93Mpps (64 byte packet size)MAC address database size :
8K (48-bit MAC ad-dresses)Jumbo frame support :
9KL2 Services - VLANs :
*IEEE 802.1Q VLAN tagging :
YesQinQ VLAN tagging :
YesIP-based VLANs :
YesMAC-based VLANs :
YesProtocol-based VLAN :
YesVoice VLAN :
YesVLAN mapping :
YesL2 Services - Availability :
*Storm control :
Yes (Broadcast, multicast, unknown unicast)IEEE 802.3ad - LAGs (LACP) :
YesIEEE 802.3x :
YesRing (ERPS,complies with G.8032) :
Yes, Recovery time < 50msIEEE 802.1D Spanning Tree Protocol :
YesIEEE 802.1w Rapid Spanning Tree Protocol :
YesIEEE 802.1s Multiple Spanning Tree Protocol :
YesLayer 2 DHCP Relay :
YesL2 Services - Multicast Filtering :
YesIGMP snooping (v1, v2 and v3) :
YesMLD snooping support (v1 and v2) :
YesIGMP snooping querier (v2) :
YesMLD snooping querier (v1) :
YesMulticast VLAN Registration (MVR) :
YesL3 Services - Routing :
*IPv4 static routing :
100IPv6 static routing :
100Link Aggregation :
*Manual LAG :
Yes# of LAGs / # of members in each LAG :
8 LAGs with max 8 members in each LAGNetwork Monitoring and Discovery Services :
*802.1ab LLDP :
YesSNMP :
v1, v2c, v3RMON group 1,2,3,9 :
YesNetwork Security :
YesIEEE 802.1x :
YesRADIUS accounting :
YesAccess Control Lists (ACLs) :
YesIP-based ACLs (IPv4 and IPv6) :
L2 / L3 / L4MAC-based ACLs :
YesTCP/UDP-based ACLs :
YesControl MAC # static entries :
48Port-based security by locked MAC addresses :
YesDynamic ARP inspection :
YesDoS protection :
YesDoS attacks prevention :
YesNetwork storm protection, DoS :
YesQuality of Service (QoS) :
*Port-based rate limiting :
Yes ingress and egressPort-based QoS :
YesSupport for IPv6 fields :
YesDiffServ QoS :
Yes ingressIEEE 802.1p COS :
YesDestination MAC and IP :
YesIPv4 and v6 DSCP :
YesTCP/UDP-based :
YesWeighted Round Robin (WRR) :
YesStrict priority queue technology :
YesIEEE Network Protocols :
*Protocols :
• IEEE 802.3 Ethernet • IEEE 802.3u 100BASE-T • IEEE 802.3ab 1000BASE-T • IEEE 802.3af PoE • IEEE 802.3at PoE+ • IEEE 802.3az Energy Efficient Ethernet (EEE) • IEEE 802.3ad Trunking (LACP) • IEEE 802.3z Gigabit Ethernet 1000BASE-SX/LXProtocols 2 :
• IEEE 802.3x Full-Duplex Flow Control • IEEE 802.1Q VLAN Tagging • IEEE 802.1AB LLDP with ANSI/TIA-1057 (LLDP-MED) • IEEE 802.1p Class of Service • IEEE 802.1D Spanning Tree (STP) • IEEE 802.1s Multiple Spanning Tree (MSTP) • IEEE 802.1w Rapid Spanning TManagement, Monitoring & Troubleshooting :
*Password management :
YesAccess control via RADIUS and TACACS+ :
YesIPv6 management :
YesSNMP v1/v2c/v3 :
YesPort mirroring :
Yes ingress and egressMany-to-one port mirroring :
6Cable test utility :
YesTLS/HTTPS Web-based access (version) :
Yes (v1.2)File transfers (uploads, downloads) :
TFTP / HTTPHTTP upload/download (firmware) :
YesSyslog (RFC 3164) :
YesLEDs :
YesPer port :
Speed, Link, Activity; PoE in different modePer device :
PowerPhysical Specifications :
*Dimensions (Width * Depth * Height) :
150 x 120 x 48 mm (5.91 x 4.72 x 1.89 in)Weight :
0.9 kg (1.98 lb)Shell protection :
P40 high-strength aluminum casePower Requirements :
DC 12~24V, redundant power with reverse polarity protectionPower Consumption :
100W (when all ports used, line-rate traffic and max PoE)Max power :
7W (worst case, all ports used, line-rate traffic) (Watts)Iddle power consumption :
5W (all ports link-down standby) (Watts)Energy Efficient Ethernet (EEE) :
Yes (deactivated by default)Environmental Specifications :
*Operating Temperature :
-40° to 85°C (-40° to 185°F)Operating Humidity :
95% maximum relative humidity (RH), non-condensingOperating Altitude :
10,000 ft (3,000 m) maximumStorage Temperature :
-40° to 85°C (-40° to 185°F)Storage Humidity (relative) :
95% maximum relative humidity, non-condensingStorage Altitude :
10,000 ft (3,000 m) maximumExecutive Standard & Protection :
*Lightning Protection :
*IEC61000-4-3 (RS) :
10V/m (80~1000MHz)FCC Part 15/CISPR22 (EN55022) :
Class BIEC61000-6-2 :
Common Industrial StandardIEC61000-4-9 (Pulsed magnet field) :
1000A/mIEC61000-4-10 (Damped oscillation) :
30A/m, 1MHzIEC61000-4-12/18 (Shockwave) :
CM 2.5kV, DM 1kVIEC61000-4-4(EFT) :
Power cable:±4kV, Data cable: ±2kVIEC61000-4-16(Common-mode transmission) :
30V, 300V, 1sIEC61000-4-2 (ESD) :
±8kV contact discharge, ±15kV air dischargeIEC61000-4-6 (Radio frequency transmission) :
10V(150kHz~80MHz)IEC61000-4-8 :
100A/m, 1000A/m, 1s-3sIEC61000-4-5 (Surge): Power cable :
CM±4kV/ DM±2kV, Data cable: ±4kVMechanical Properties :
*IEC60068-2-6 :
Anti VibrationIEC60068-2-32 :
Free FallIEC60068-2-27 :
Anti ShockElectromagnetic Emissions and Immunity :
*Certifications :
CE mark, commercial; FCC Part 15 Class A, VCCI Class A; Class A EN 55022 (CISPR 22) Class A; Class A C-Tick; EN 55024; CCC; 47 CFR FCC Part 15, SubpartB, Class A ICES-003: 2016 Issue 6, Class A; ANSI C63.4:2014; IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013Safety :
*Safety Certifications :
CB mark, commercial; CSA certified (CSA 22.2 #950); UL listed (UL 1950)/cUL IEC 950/EN 60950; EN 60950-1: 2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013 IEC 60950-1:2005 ;(ed.2)+A1:2009+A2:2013; AN/NZS 60950.1:2015; CCC (China Compulsory Certificate)Warranty and Support :
*Hardware Limited Warranty :
Limited Lifetime*Technical Support via Phone and Email* :
Limited Lifetime*24x7 Online Chat Technical Support :
Limited Lifetime*Package Contents :
*All models :
Industrial Switch ; Brackets and screws for DIN-Rail mounting, which are already installed in the switch; Rubber protection caps, which are already installed in the SFP sockets Installation guideBusiness Type :
IndustrialBandridth :
1GMore Filters :
L2+ Managed
Questions & Answers
1. What is the PoE power output per port?
Each port supports up to 30W of PoE power, sufficient for most PoE-enabled devices like cameras and access points.
2. How many devices can this switch power simultaneously?
The switch can power up to 4 PoE-enabled devices at once, within a total power budget of 100W.
3. What is the input power requirement for this switch?
It accepts DC input from 12V to 24V, with a built-in booster to provide 48V for PoE devices.
4. Can this switch operate in outdoor or harsh environments?
Yes, with an IP40-rated enclosure and an operating temperature range of -40°C to 85°C, it is suitable for rugged conditions.
5. Does this switch support fiber connections?
Yes, it has two SFP slots for Gigabit fiber connections, offering flexibility for long-distance uplinks.
6. What PoE standards does this switch support?
It supports IEEE 802.3af/at PoE standards for powering devices.
7. What is the maximum data transfer speed?
The switch supports Gigabit Ethernet speeds, offering up to 1 Gbps per port.
8. Does the switch support advanced traffic management features?
Yes, it supports QoS for traffic prioritization, ensuring optimal performance for critical applications.
9. What network redundancy features does this switch offer?
The switch supports ERPS, STP, RSTP, and MSTP to ensure redundancy and prevent network loops.
10. Is this switch easy to install?
Yes, it features DIN-rail mounting, which ensures secure installation in vehicles or industrial environments.
