Overview
8 Ports Gigabit M12 PoE Switch,Up to 30 watts for each PoE port, Industrial Protection IP67 Rating, Wall Mount, IES7231C-4PGE1GE-M12
Physical Port
Power over Ethernet
|
Switching
Hardware
|
Features
Rugged M12 Ethernet Ports
Designed with 8 Gigabit M12 Ethernet ports, the IES7231C-8PGE-M12 ensures stable, high-speed network connectivity in rugged environments. The M12 connectors provide secure locking mechanisms, preventing disconnections due to vibrations or movement, ideal for industrial and transportation systems like trains or factory floors.
PoE+ Power Delivery
Each port supports IEEE 802.3af/at PoE standards, delivering up to 30W per port, allowing the switch to power devices such as IP cameras, wireless access points, and sensors. This feature eliminates the need for additional power supplies, reducing cable clutter and simplifying installations in remote or challenging locations.
IP67 Industrial Protection
The IES7231C-8PGE-M12 features an IP67-rated enclosure, offering protection from dust, water, and harsh weather conditions. This makes it perfect for outdoor and extreme industrial applications, such as oil rigs, marine settings, or factory automation systems, ensuring reliable performance under demanding circumstances.
High ESD and Surge Protection
With high-level electrostatic discharge (ESD) protection (±8KV DC contact, ±15KV air discharge), this M12 PoE switch is resistant to electrical surges, providing enhanced durability and reliability, especially in areas prone to lightning strikes or other electrical fluctuations.
Wide Operating Temperature Range
The IES7231C-8PGE-M12 operates reliably in extreme temperatures ranging from -40°C to 85°C. This wide operating temperature range ensures the switch can function effectively in environments with significant temperature variations, such as deserts or cold-storage facilities.
Efficient Data Forwarding
The IES7231C-8PGE-M12 offers a backplane bandwidth of 16Gbps and a packet forwarding rate of 7.45Mpps, enabling fast and efficient data transmission. This makes it suitable for data-intensive applications like video surveillance, real-time data collection, or IoT networks.
Compact and Flexible Installation
This M12 PoE switch is designed for wall-mount installation, offering flexibility in placement, especially in tight or space-constrained environments. Its compact size allows it to be integrated seamlessly into industrial cabinets or mounted on machinery.
Connectivity Solutions
8 Port Gigabit M12 PoE switch connectivity solution
Specification
Technical Specifications :
IES7231C-8PGE-M1210/100/1000M M12 copper ports :
8PoE / PoE+ ports :
8Power over Ethernet :
*PoE Standard :
IEEE 802.3at Power over Ethernet Plus/PSE; Backward compatible with IEEE 802.3af Power over EthernetPoE Power Supply Type :
End-span: 1/2 (+), 3/6 (-)PoE Power Output :
Per port 52V DC, 300mA. max. 15.4 watts (IEEE 802.3af); Per port 52V DC, 600mA. max. 30 watts (IEEE 802.3at)Performance Specification :
*Packet buffer memory :
1.2 MbForwarding modes :
Store-and-forwardBandwidth :
16 GbpsPacket forwarding rate :
11.91MppsMAC address database size :
4K (48-bit MAC ad-dresses)Jumbo frame support :
9KIEEE Network Protocols :
*Protocols :
• IEEE 802.3 Ethernet • IEEE 802.3u 100BASE-T • IEEE 802.3ab 1000BASE-T • IEEE 802.3z Gigabit Ethernet 1000BASE-SX/LX • IEEE 802.3af PoE • IEEE 802.3at PoE+ • IEEE 802.3az Energy Efficient Ethernet (EEE) • IEEE 802.3x Full-Duplex Flow ControlMonitoring :
*LEDs :
YesPer port :
Speed, Link, Activity; PoE in different modePer device :
PowerDimensions (Width * Depth * Height) :
194 × 123 × 33 mm (7.64 x 4.84 x 1.3 in)Weight :
1.2 kg (2.65 lb)Shell protection :
IP67 high-strength aluminum casePower Requirements :
DC 48~56V, with reverse polarity protectionPower Consumption :
*Max power :
8W (worst case, all ports used, line-rate traffic) (Watts)Iddle power consumption :
5W (all ports link-down standby) (Watts)Energy Efficient Ethernet (EEE) :
Yes (deactivated by default)Fan :
FanlessEnvironmental Specifications :
*Operating Temperature :
-40° to 85°C (-40° to 185°F)Operating Humidity :
95% maximum relative humidity (RH), non-condensingOperating Altitude :
10,000 ft (3,000 m) maximumStorage Temperature :
-40° to 85°C (-40° to 185°F)Storage Humidity (relative) :
95% maximum relative humidity, non-condensingStorage Altitude :
10,000 ft (3,000 m) maximumExecutive Standard & Protection :
*Lightning Protection :
*IEC61000-4-3 (RS) :
10V/m (80~1000MHz)FCC Part 15/CISPR22 (EN55022) :
Class BIEC61000-6-2 :
Common Industrial StandardIEC61000-4-9 (Pulsed magnet field) :
1000A/mIEC61000-4-10 (Damped oscillation) :
30A/m, 1MHzIEC61000-4-12/18 (Shockwave) :
CM 2.5kV, DM 1kVIEC61000-4-4(EFT) :
Power cable:±4kV, Data cable: ±2kVIEC61000-4-16(Common-mode transmission) :
30V, 300V, 1sIEC61000-4-2 (ESD) :
±8kV contact discharge, ±15kV air dischargeIEC61000-4-6 (Radio frequency transmission) :
10V(150kHz~80MHz)IEC61000-4-8 :
100A/m, 1000A/m, 1s-3sIEC61000-4-5 (Surge): Power cable :
CM±4kV/ DM±2kV, Data cable: ±4kVMechanical Properties :
*IEC60068-2-6 :
Anti VibrationIEC60068-2-32 :
Free FallIEC60068-2-27 :
Anti ShockElectromagnetic Emissions and Immunity :
*Certifications :
CE mark, commercial; FCC Part 15 Class A, VCCI Class A; Class A EN 55022 (CISPR 22) Class A; Class A C-Tick; EN 55024; CCC; 47 CFR FCC Part 15, SubpartB, Class A ICES-003: 2016 Issue 6, Class A; ANSI C63.4:2014; IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013Safety :
*Safety Certifications :
CB mark, commercial; CSA certified (CSA 22.2 #950); UL listed (UL 1950)/cUL IEC 950/EN 60950; EN 60950-1: 2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013 IEC 60950-1:2005 ;(ed.2)+A1:2009+A2:2013; AN/NZS 60950.1:2015; CCC (China Compulsory Certificate)Warranty and Support :
*Hardware Limited Warranty :
Limited Lifetime*Technical Support via Phone and Email* :
Limited Lifetime*24x7 Online Chat Technical Support :
Limited Lifetime*Package Contents :
*All models :
Industrial PoE Switch;Manual;Screws for wall mounting;Business Type :
IndustrialBandridth :
1GMore Filters :
Unmanaged
