Overview
S7200-16GE, 16 Ports Ethernet Switch,10/100/1000M, Desktop and Rack mount, Fanless silent design
Features
16 Gigabit Ethernet Ports
Each port supports speeds of 10/100/1000 Mbps, ensuring high-performance connectivity for various devices. This allows simultaneous and seamless data transmission, ideal for video streaming, online gaming, and transferring large files. The ports feature auto-sensing technology to detect device speed, optimizing network performance.
Plug-and-Play Installation
No complex configurations are required—simply plug in your devices to expand your network. This feature ensures that users with limited technical knowledge can easily integrate the switch into their setup, saving time and effort while minimizing downtime.
Fanless, Silent Operation
The fanless design eliminates noise, making it perfect for environments such as home offices, classrooms, or libraries. This ensures quiet operation without compromising performance, making it suitable for use in noise-sensitive settings.
Energy-Efficient Technology
Built-in energy-saving mechanisms automatically reduce power consumption for inactive or low-traffic ports. This feature makes the switch an eco-friendly choice, reducing electricity bills while maintaining optimal network performance.
Durable Metal Housing
Encased in a sturdy metal shell, the switch offers long-lasting durability and better heat dissipation. Its robust design ensures reliability, even under continuous operation, making it ideal for professional and industrial environments.
Supports Extensive Device Connectivity
Easily connect multiple devices such as computers, IP cameras, printers, and smart TVs. This switch is perfect for expanding network capabilities in small businesses, retail setups, or homes, enabling high-speed internet access and uninterrupted data transfer across all connected devices.
Connectivity Solutions
16 port gigabit ethernet switch connection solution for home network
Specification
Technical Specifications :
S7200-16GE10M/100M/1G RJ45 copper ports :
16Performance Specification :
*Packet buffer memory :
0.8 MbForwarding modes :
Store-and-forwardBandwidth :
48 GbpsPacket forwarding rate :
23.81Mpps (64 byte packet size)MAC address database size :
4K (48-bit MAC ad-dresses)Mean Time Between Failures :
116,113 hours (MTBF) @ 25°C100M Copper Latency :
8.521µs; 8.622µs; 8.735µs1G Copper Latency :
3.443µs; 3.552µs; 3.633µsIEEE Network Protocols :
*Protocols :
• IEEE 802.3 Ethernet • IEEE 802.3u 100BASE-T• IEEE 802.3ab 100BASE-T • IEEE 802.3az Energy Efficient Ethernet (EEE) • IEEE 802.3x Full-Duplex Flow ControlMonitoring :
*LEDs :
YesPer port :
Speed, Link, Activity;Per device :
PowerPhysical Specifications :
*Dimensions (Width * Depth * Height) :
280 x 180 x 44.5mm (11.02in x 7.08in x 1.75 in)Weight :
1.2 kg (2.65 lb)Max power :
8WIddle power consumption :
5WEnergy Efficient Ethernet (EEE) :
Yes (deactivated by default)Fan :
FanlessEnvironmental Specifications :
*Operating Temperature :
-20° to 50°C (-4° to 122°F)Operating Humidity :
90% maximum relative humidity (RH), non-condensingOperating Altitude :
10,000 ft (3,000 m) maximumStorage Temperature :
-30° to 70°C (-22° to 158°F)Storage Humidity (relative) :
95% maximum relative humidity, non-condensingStorage Altitude :
10,000 ft (3,000 m) maximumElectromagnetic Emissions and Immunity :
*Certifications :
CE mark, commercial； FCC Part 15 Class A, VCCI Class A； Class A EN 55022 (CISPR 22) Class A； Class A C-Tick； EN 55024； CCC； 47 CFR FCC Part 15, SubpartB, Class A ICES-003: 2016 Issue 6, Class A； ANSI C63.4:2014； IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013Safety :
*Safety Certifications :
CB mark, commercial； CSA certified (CSA 22.2 #950)； UL listed (UL 1950)/cUL IEC 950/EN 60950； EN 60950-1: 2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013 IEC 60950-1:2005 ；(ed.2)+A1:2009+A2:2013； AN/NZS 60950.1:2015； CCC (China Compulsory Certificate)Warranty and Support :
*Hardware Limited Warranty :
Limited Lifetime*Technical Support via Phone and Email* :
Limited Lifetime*24x7 Online Chat Technical Support :
Limited Lifetime*Package Contents :
*All models :
Network Switch；Power adapter (localized to region of sale)Business Type :
CommercialBandridth :
1GMore Filters :
Unmanaged
Questions & Answers
1. Can the S7200-16GE handle multiple high-demand applications at once?
Yes, the S7200-16GE supports 16 gigabit ports, providing high-speed, stable connectivity for multiple devices, making it ideal for streaming, gaming, file sharing, and other data-intensive tasks simultaneously.
2. Is the S7200-16GE easy to install and set up?
Yes, it features a plug-and-play design, so no complex configurations are needed. Simply connect your devices, and the switch will start working immediately.
3. Does this 16-port gigabit network switch offer both desktop and rack mounting options?
Yes, the S7200-16GE is versatile, with both desktop and rack-mounting options available to fit various installation needs, whether at home or in an office environment.
4. Is the S7200-16GE silent in operation?
Yes, the fanless design ensures quiet operation, making the switch suitable for noise-sensitive environments like offices, home offices, or living rooms.
5. How energy-efficient is the S7200-16GE?
The S7200-16GE incorporates energy-efficient technology that reduces power consumption while maintaining high performance, helping to lower operating costs.
