Overview
S7200-5GE, 5 Ports 10/100/1000M Ethernet Switch, Desktop and wall mount, Fanless silent design
Physical Port
- 8-10/100BASE-TX Fast Ethernet RJ45 ports
Switching
- Backplane bandwidth 1.6Gbps,Packet forwarding rate 0.75Mpps,MAC address 2k
- Hardware-based 10/100Mbps (half/full duplex)auto-negotiation and auto MDI/MDI-X
- Features Store-and-Forward mode with wire-speed filtering and forwarding rates
- IEEE 802.3x flow control for full duplex operation and back pressure for half duplex operation
Hardware
- Industrial Case and Installation
- IP30 High- strength Aluminum case
- DIN-rail mount design
- 48~56V DC, redundant power with reverse polarity protection
- Supports 8KV DC Ethernet ESD protection
- -30 to 75 degrees C operating temperature
- LED indicators for Power,PoE Working and LINK/ACT
Features
Wire-speed Forwarding High Speed Connection
Benchu group's 8-Port Gigabit Ethernet Switch S7200-8GE is ideal for homes with multiple devices, such as computers, smart TVs, gaming consoles, and network-attached storage (NAS) devices. By providing multiple Gigabit ports, it allows all your wired devices to connect to the network with high-speed and reliable performance. This connectivity ensures that each device can operate at optimal speeds without experiencing bottlenecks or slowdowns, even when multiple devices are in use simultaneously.
Wide Operating Temperature Design gives to Enhanced Reliability
Benchu group' s 8 port gigabit ethernet IES7211-8E-DC within wide temperature design ensures the Ethernet switch operates reliably in varying environmental conditions. It can withstand high and low temperatures, ensuring consistent performance even during extreme weather conditions. This reliability is crucial for home networks where maintaining a stable internet connection is essential for work, entertainment, and smart home devices.
Connectivity Solutions
5 port gigabit ethernet switch connection solution for home network
Specification
Technical Specifications :
S7200-5GE10M/100M/1G RJ45 copper ports :
5Performance Specification :
*Packet buffer memory :
0.4 MbForwarding modes :
Store-and-forwardBandwidth :
10 GbpsPacket forwarding rate :
0.744Mpps (64 byte packet size)MAC address database size :
2K (48-bit MAC ad-dresses)Mean Time Between Failures :
121,221 hours (MTBF) @ 25°C100M Copper Latency :
8.521µs; 8.622µs; 8.735µs1G Copper Latency :
3.443µs; 3.552µs; 3.633µsIEEE Network Protocols :
*Protocols :
• IEEE 802.3 Ethernet • IEEE 802.3u 100BASE-T • IEEE 802.3ab 100BASE-T • IEEE 802.3az Energy Efficient Ethernet (EEE) • IEEE 802.3x Full-Duplex Flow ControlMonitoring :
*LEDs :
YesPer port :
Speed, Link, Activity;Per device :
PowerPhysical Specifications :
*Dimensions (Width * Depth * Height) :
100 x 70 x 25mm (3.94 x 2.76 x 0.98 in)Weight :
0.25 kg (0.55 lb)Max power :
3WIddle power consumption :
2WEnergy Efficient Ethernet (EEE) :
Yes (deactivated by default)Fan :
FanlessEnvironmental Specifications :
*Operating Temperature :
-20° to 50°C (-4° to 122°F)Operating Humidity :
90% maximum relative humidity (RH), non-condensingOperating Altitude :
10,000 ft (3,000 m) maximumStorage Temperature :
-30° to 70°C (-22° to 158°F)Storage Humidity (relative) :
95% maximum relative humidity, non-condensingStorage Altitude :
10,000 ft (3,000 m) maximumElectromagnetic Emissions and Immunity :
*Certifications :
CE mark, commercial; FCC Part 15 Class A, VCCI Class A; Class A EN 55022 (CISPR 22) Class A; Class A C-Tick; EN 55024; CCC; 47 CFR FCC Part 15, SubpartB, Class A ICES-003: 2016 Issue 6, Class A; ANSI C63.4:2014; IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013Safety :
*Safety Certifications :
CB mark, commercial; CSA certified (CSA 22.2 #950); UL listed (UL 1950)/cUL IEC 950/EN 60950; EN 60950-1: 2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013 IEC 60950-1:2005 ;(ed.2)+A1:2009+A2:2013; AN/NZS 60950.1:2015; CCC (China Compulsory Certificate)Warranty and Support :
*Hardware Limited Warranty :
Limited Lifetime*Technical Support via Phone and Email* :
Limited Lifetime*24x7 Online Chat Technical Support :
Limited Lifetime*Package Contents :
*All models :
Network Switch;Power adapter (localized to region of sale)Business Type :
CommercialBandridth :
1GMore Filters :
Unmanaged
Questions & Answers
1. Does the S7200-5GE support high-speed applications like gaming or streaming?
Yes, the S7200-5GE provides Gigabit Ethernet speeds (up to 1000 Mbps) on all ports, ensuring smooth and uninterrupted performance for high-bandwidth activities like gaming, video streaming, and file transfers.
2. Can the S7200-5GE be installed easily?
Yes, the S7200-5GE has a plug-and-play design, making installation quick and easy without the need for any complex configurations or technical expertise.
3. Is the S7200-5GE suitable for home office environments?
Yes, its fanless design ensures silent operation, making it ideal for noise-sensitive environments like home offices or living rooms where quiet performance is important.
4. Can the S7200-5GE be mounted on the wall?
Yes, the S7200-5GE features a wall-mountable design, offering flexible installation options to optimize space in homes or small offices.
5. Is this 8-port gigabit ethernet switch energy-efficient?
Yes, the S7200-5GE includes energy-saving technologies, ensuring low power consumption while providing reliable, high-speed network connectivity, making it an eco-friendly choice for home networking.
