16 Ports Unmanaged PoE+ Switch, 2-1Gb RJ45 Uplink, 1-1Gb SFP,16 PoE+ Ports@180W Power Budget, Three modes: AI/VLAN/250m, Rack-Mount,Fanless, SP5210-16PFE2GE1GF

ethernet switch 16 ports poe
poe unmanaged switch 16 port
unmanaged switch 16 port poe
16 port 10/100m poe switch price
16 port 10/100m unmanaged poe switch with 2 gigabit RJ45 and 1 sfp size

16 Ports Unmanaged PoE+ Switch, 2-1Gb RJ45 Uplink, 1-1Gb SFP,16 PoE+ Ports@180W Power Budget, Three modes: AI/VLAN/250m, Rack-Mount,Fanless, SP5210-16PFE2GE1GF

Inquire Now

Designed for IP Camera/Wireless Access Point

Product Highlights
    • 16-10/100Mbps RJ45 ports
    • 2-10/100/1000Mbps RJ45 ports
    • 1-1.25Gbps mini-GBIC SFP interface
    • 16 ports supporting PoE+ to PD device
    • Complies with IEEE 802.3af/at Power over Ethernet end-span
    • Supports PoE power up to 30 watts for each PoE port
    • 162-watt PoE budget,180-watt total Power budget
    • Supports " Default " "AI""Extend" "VLAN"mode selection;
    • Supports contact discharge of ±4KV DC and air discharge of ±6KV DC for Ethernet ESD protection
    • Backplane bandwidth 7.6Gbps，Packet forwarding rate 4.2Mpps，MAC address 2k
    • Desktop palm size，Internal AC power supply

16 Ports Unmanaged PoE+ Switch, 2-1Gb RJ45 and 1-1Gb SFP Uplink

Overview



SP5210-16PFE2GE1GF, 16 Ports 100M PoE+ Switch，with 2-1Gb RJ45 Uplink，with 1-1Gb SFP，16 PoE+ Ports@180W Power Budget，Three modes:AI/VLAN/250m, Rack-Mount, Fanless

The SP5210-16PFE2GE1GF is a 16-port unmanaged PoE switch from Benchu Group, designed to deliver efficient, reliable, and cost-effective networking solutions for small businesses and workgroups. Equipped with sixteen 10/100 Mbps PoE+ ports, each supporting up to 30 watts of power, it enables seamless connection of devices such as IP cameras, wireless access points, and VoIP phones. For enhanced network integration and high-speed uplink capabilities, it features two Gigabit RJ45 uplink ports and one Gigabit SFP port.



This switch offers a total power budget of 180 watts, providing sufficient capacity to support multiple devices simultaneously. Its three operational modes—AI, VLAN, and 250m—enhance functionality. The AI mode optimizes intelligent traffic management, VLAN mode isolates traffic for improved security, and the 250m mode extends PoE transmission distances, making it suitable for larger or complex deployments.



The rack-mountable, fanless design ensures silent operation and space efficiency, ideal for offices, retail spaces, and quiet environments. Plug-and-play installation simplifies setup, while non-blocking wire-speed performance ensures smooth and reliable data transmission. The SP5210-16PFE2GE1GF adds value by reducing deployment costs, offering flexible connection options, and ensuring scalability for expanding network requirements, making it a top choice for cost-conscious users.



  • Physical Port
    16-10/100Mbps Fast Ethernet ports
    2-10/100/1000Mbps Gigabit Ethernet port
    1-1.25Gbps mini-GBIC SFP interface

    Power over Ethernet
    16 ports supporting PoE to PD device (Port 1 to port 16)
    Complies with IEEE 802.3af/at Power over Ethernet end-span
    Supports PoE Power up to 30 watts for each PoE port
    162-watt PoE budget, 180-watt total power budget
    Hardware DIP switch for "Default", “AI”“VLAN” and “Extend” mode selection;
    Supports PoE watch-dog in AI mode: Realtime monitoring PoE load device's status and will automatically reboot PoE port when the connected device is not active.
    Supports 25-watt PoE transmit distance of 250m in extend mode
    Remote power feeding up to 100m in Default mode
    Auto detects powered device (PD)
  • Switching
    Hardware-based 10/100/1000Mbps auto-negotiation and auto MDI/MDI-X
    Flow control for full duplex operation and back pressure for half duplex operation
    Integrates address look-up engine, supporting 4K absolute MAC addresses
    Automatic address learning and address aging
    Solid DIP switch to isolate ports to prevent broadcast storm and defend DHCP spoofing
    Supports Energy-Efficient Ethernet (EEE) function (IEEE 802.3az)
  • Hardware
    High-strength metal casing.
    11-inch Rack-Mount size, 1U height
    LED indicators for PoE ready/activity and LINK/ACT
    Fanless design
    Internal AC power supply






Features



Fast Port and gigabit port and fiber Port Configuration

16 × PoE+ 10/100Mbps RJ45 ports provide up to 30W per port and total Power budget of 180W, together with 2 × 10/100/1000M RJ45 for uplink connections,with 1 x 1.25G SFP Fort to extend the network transmission distance.

16 Ports 10/100M PoE Switch with 2 Gigabit RJ45 and 1SFP



Two Gigabit RJ45 and 1 Gigabit SFP Uplink Ports

The SP5210-16PFE2GE1GF with two uplink ports with 10/100/1000Mbps transfer rate to ensure high-speed data and video transmission, reliable assurance for connection between the surveillance system and outside network where the 16 PoE+ ports can be used to their full potential. Fiber-Optic Link Capability Enables Extension of Network Deployment,The distance can be extended from 550 meters to 2 kilometers (multi-mode fiber) and 10/20/30/40/50/60/70/120 kilometers (single-mode fiber or WDM fiber). They are well suited for applications to uplink to backbone switch and monitoring center in long distance.









Supports " Default " "AI""Extend" "VLAN"mode selection;

The "Extend" mode features 30-watt PoE transmit distance of 250meter at speed of 10Mbps,The "AI" mode features the PoE Switch starts to detect whether the port is transmitting data. If the port does not transmit data and the duration exceeds a specific time, PoE will automatically power off and then re-power.The “VLAN” operation mode features port-based VLAN function that helps to prevent the multicast or broadcast storm from influencing each other.



AI PoE Switch 16Port





Cost Savings on Climate Control（Wide temperature design -20~50℃）
Using PoE switches with a wide temperature range reduces the need for expensive climate control solutions in environments where temperature regulation is challenging or impractical. This reduction in HVAC requirements leads to significant cost savings in energy consumption and maintenance. By operating efficiently in varying temperatures, these switches help organizations minimize their environmental footprint and reduce operational expenses. The cost savings can be redirected to other areas of the network infrastructure, enhancing overall efficiency and enabling further technological advancements without compromising on reliability or performance.


16 ports 10/100M PoE Switch Wide temperature design





6KV Lightning Protection design Compliance with Industry Standards

The SP5210-16PFE2G1GF PoE Switches equipped with 6KV lightning protection often meet or exceed industry standards and regulatory requirements for electrical safety and surge protection. Compliance with these standards ensures that the switches are built to withstand electrical surges and provide reliable performance in various environments. This adherence to industry norms enhances the credibility and marketability of the PoE switches, as customers and stakeholders recognize the value of certified and compliant equipment. Organizations that prioritize safety and reliability in their network infrastructure benefit from using switches that meet stringent protection standards, ensuring optimal performance.



16 port unmanaged poe switch Lightning Protection







Connectivity Solutions



Unmanaged PoE Switch 16 Port of Perfectly-integrated Solution for PoE IP Camera



16 Ports 10/100M PoE Swtich Connectivity Solutions





Specification



  • Technical Specifications :

    SP5210-16PFE2GE1GF

  • 10M/100M RJ45 copper ports :

    16

  • 10M/100M/1G RJ45 copper ports :

    2

  • 1.25G SFP (fiber) ports :

    1

  • PoE / PoE+ ports :

    16

  • Power over Ethernet :

    *

  • PoE Standard :

    IEEE 802.3at Power over Ethernet Plus/PSE； Backward compatible with IEEE 802.3af Power over Ethernet

  • PoE Power Supply Type :

    End-span: 1/2 (+), 3/6 (-)

  • PoE Power Output :

    Per port 52V DC, 300mA. max. 15.4 watts (IEEE 802.3af)； Per port 52V DC, 600mA. max. 30 watts (IEEE 802.3at)

  • PoE Power Budget :

    162

  • Number of PDs, 7 watts :

    16

  • Number of PDs, 15 watts :

    11

  • Number of PDs, 30 watts :

    6

  • Performance Specification :

    *

  • Chip :

    Realtek

  • Packet buffer memory :

    1.6 Mb

  • Forwarding modes :

    Store-and-forward

  • Bandwidth :

    10.08 Gbps

  • Packet forwarding rate :

    6.5Mpps (64 byte packet size)

  • MAC address database size :

    4K (48-bit MAC ad-dresses)

  • Jumbo frame support :

    9K

  • Mean Time Between Failures :

    Store and Forward(Full Wire Speed)

  • 100M Copper Latency :

    110,232 hours

  • 1G Copper Latency :

    3.543µs; 3.552µs; 3.633µs

  • 1G Fiber Latency :

    2.995µs; 3.113µs; 3.181µs

  • IEEE Network Protocols :

    *

  • Protocols :

    • IEEE 802.3 Ethernet • IEEE 802.3u 100BASE-T • IEEE 802.3ab 1000BASE-T • IEEE 802.3z Gigabit Ethernet 1000BASE-SX/LX• IEEE 802.3af PoE • IEEE 802.3at PoE+ • IEEE 802.3az Energy Efficient Ethernet (EEE) • IEEE 802.3x Full-Duplex Flow Control

  • Monitoring :

    *

  • LEDs :

    Yes

  • Per port :

    Speed, Link, Activity; PoE in different mode

  • Per device :

    Power

  • Physical Specifications :

    *

  • Dimensions (Width * Depth * Height) :

    285 x 190 x 44.5mm (11.22 x 7.48 x 1.75 in)

  • Weight :

    1.9 kg (4.19 lb)

  • Power Consumption :

    180W (when all ports used, line-rate traffic and max PoE)

  • Max power :

    15W (worst case, all ports used, full PoE, line-rate traffic)

  • Iddle power consumption :

    10W (all ports link-down standby)(Watts)

  • Energy Efficient Ethernet (EEE) :

    Yes (deactivated by default)

  • Fan :

    Fanless

  • Environmental Specifications :

    *

  • Operating Temperature :

    -20° to 50°C (-4° to 122°F)

  • Operating Humidity :

    90% maximum relative humidity (RH), non-condensing

  • Operating Altitude :

    10,000 ft (3,000 m) maximum

  • Storage Temperature :

    –20° to 70°C (– 4° to 158°F)

  • Storage Humidity (relative) :

    95% maximum relative humidity, non-condensing

  • Storage Altitude :

    10,000 ft (3,000 m) maximum

  • Electromagnetic Emissions and Immunity :

    *

  • Certifications :

    CE mark, commercial； FCC Part 15 Class A, VCCI Class A； Class A EN 55022 (CISPR 22) Class A； Class A C-Tick； EN 55024； CCC； 47 CFR FCC Part 15, SubpartB, Class A ICES-003: 2016 Issue 6, Class A； ANSI C63.4:2014； IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013

  • Safety :

    *

  • Safety Certifications :

    CB mark, commercial； CSA certified (CSA 22.2 #950)； UL listed (UL 1950)/cUL IEC 950/EN 60950； EN 60950-1: 2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013 IEC 60950-1:2005 ；(ed.2)+A1:2009+A2:2013； AN/NZS 60950.1:2015； CCC (China Compulsory Certificate)

  • Warranty and Support :

    *

  • Hardware Limited Warranty :

    Limited Lifetime*

  • Technical Support via Phone and Email* :

    Limited Lifetime*

  • 24x7 Online Chat Technical Support :

    Limited Lifetime*

  • Package Contents :

    *

  • All models :

    Smart Switch； AC Power cord with C13 connector (localized to region of sale) ； Brackets and screws for rack mounting； Rubber protection caps, which are already installed in the SFP sockets Installation guide

  • Business Type :

    Commercial

  • Bandridth :

    100M+1G

  • More Filters :

    Unmanaged

Videos









Questions & Answers

Q: What is the maximum power output per port on the 16-port 100M PoE switch?
A1: Each PoE port typically delivers up to 30W of power, compliant with IEEE 802.3at (PoE+), suitable for powering devices like IP cameras, wireless access points, and VoIP phones.

Q: How do the gigabit network ports benefit the 16 Port 10/100M PoE switch?
A2: The two gigabit network ports provide high-speed uplink connections, ensuring efficient data transfer to the core network or other switches, enhancing overall network performance.

Q: What is the purpose of the gigabit optical port?
A: The gigabit optical port allows for fiber optic connections, offering extended range and high-speed data transmission, ideal for long-distance links and backbone network integration.

Q: Can this switch support both data and power transmission over Ethernet cables?
A4: Yes, the 16 PoE ports support simultaneous data and power transmission over a single Ethernet cable, simplifying the installation and powering of PoE-enabled devices.

Q: Is the switch suitable for both small and large network deployments?
A: Yes, the switch is versatile, suitable for small to large network deployments, offering ample PoE ports for device connectivity and high-speed uplink and optical ports for efficient data transfer.

Q: How do I monitor the power status of connected devices?
A: The 16 Ports PoE switch have LED indicators next to each port that light up when a device is connected and receiving power, providing a visual confirmation of the PoE status.
